: MPQ4314-AEC1TYPE SEB
FAST ACTING GLASS TUBE FUSES SERIES

产品名称：MPQ4314-AEC1

TYPE SEB FAST ACTING GLASS TUBE FUSES SERIES2022-05-30 14:56:59 更新

特征：45V, 4A, Low IQ, Synchronous Step-Down Converter with Frequency Spread Spectrum, AEC-Q100 Qualified

基本介绍 替代型号 购买渠道

▍产品百科

特性

• Wide 3.3V to 45V Operating Input Voltage (VIN) Range
• 4A Continuous Output Current (IOUT)
• 7μA Low Shutdown Current
• 18μA Sleep Mode Quiescent Current (IQ)
• Internal 48mΩ High-Side MOSFET (HS-FET) and 20mΩ Low-Side MOSFET (LS-FET)
• 350kHz to 1000kHz Configurable Switching Frequency (fSW) for Car Battery Applications
• Synchronize to External Clock
• Out-of-Phase Synchronized Clock Output
• 3V Fixed Output
• Frequency Spread Spectrum (FSS) for EMI Reduction
• Symmetric VIN for EMI Reduction
• Power Good (PG) Output
• External Soft Start (SS)
• 100ns Minimum On Time (tON_MIN)
• Selectable Advanced Asynchronous Modulation (AAM) Mode or Forced Continuous Conduction Mode (FCCM)
• Low-Dropout (LDO) Mode
• Over-Current Protection (OCP) with Hiccup Mode

• Available in a QFN-20 (4mmx4mm) Package
