• Designed for Automotive Applications:• Wide 3.3V to 40V Operating Input Voltage (VIN) Range
• Low-Dropout Mode
• 6A Continuous Output Current (IOUT)
• 100ns Minimum On Time (tON_MIN)
• Multi-Phase Capability
• -40°C to +150°C Junction Temperature (TJ) Range
• Available in AEC-Q100 Grade 1

• Increased Battery Life:• Low 1.7μA Shutdown Current (ISD)
• 22μA Quiescent Current (IQ) with Switching
• Advanced Asynchronous Modulation (AAM) Mode Increases Efficiency at Light Loads

• High Performance for Improved Thermals:• Internal 50mΩ High-Side MOSFET (HS-FET) and 22mΩ Low-Side MOSFET (LS-FET)

• Optimized for EMC/EMI:• 350kHz to 1000kHz Configurable Switching Frequency (fSW)
• Up to 2.2MHz Configurable fSW for ≥5V  VOUT Car Battery Applications
• Symmetric VIN Pinout
• Synchronized to External Clock
• Out-of-Phase Synchronized Clock Output
• CISPR25 Class 5 Compliant
• MeshConnect™ Flip-Chip Package

• Additional Features:• Power Good (PG) Output
• External Soft Start (SS)
• Over-Current Protection (OCP) with Hiccup Mode

• Available in a QFN-20 (4mmx4mm) Package with Wettable Flank
