• 5V to 36V Operating Input Voltage (VIN) Range
• 6 Channels with Maximum 150mA per Channel
• 100mΩ, 50V Internal MOSFET
• Up to 2.2MHz Configurable Switching Frequency (fSW)
• External Sync SW Function
• Multiple Dimming Modes via the Pulse-Width Modulation (PWM) Input:• Direct PWM Dimming
• Analog Dimming
• Mix Dimming with 25% or 12.5% Transfer Point

• 15000:1 Dimming Ratio during PWM Dimming when fPWM≤ 200Hz
• 200:1 Dimming Ratio during Analog Dimming via PWM Dimming Signal Input
• Excellent EMI Performance
• Frequency Spread Spectrum (FSS)
• I2C Interface, 3 Selectable IC Addresses
• Phase Shift Function for PWM Dimming
• 5% Current Matching
• Cycle-by-Cycle Current Limiting
• VOUTDisconnect from VIN
• LED Current Decreases Automatically at High Temperatures
• LED Short/Open Protection
• Over-Current Protection (OCP)
• Over-Temperature Protection (OTP)
• Inductor Short Protection
• Configurable LED Short Protection Threshold
• Configurable Over-Voltage Protection (OVP) Threshold
• Fault Indicator Signal Output
• Available in a QFN-24 (4mmx4mm) Package

• Available in AEC-Q100 Grade 1
