• Supports BC1.2 CDP Mode
• Supports USB Type-C 5V @ 3A DFP Mode
• USB_OUT, DP/DM, CC1/CC2 Pins Short-to-Battery Protection
• Wide 4.2V to 36V Continuous Operating Input Voltage (VIN) Range
• Passes Apple MFI R33 Certification Test
• USB-IF Type-C Certified
• 420kHz Selectable Switching Frequency (fSW) (2.2MHz with Spread Spectrum)
• Integrated, High-Bandwidth USB2.0 Data Switch with Over-Voltage Protection (OVP)
• Adjustable Line Drop Compensation
• Accurate 3.55A and 2.85A USB Current Limit
• Integrated 20mΩ Low RDS(ON) USB MOSFET
• 145°C Internal Load-Shedding Entry Temperature
• Enable (EN) Shutdown Discharge Function
• Over-Current Protection (OCP)
• Over-Voltage Protection (OVP)
• Over-Temperature Detection (OTP)
• Fault Indication for OCP, OVP, and OTP
• 200kHz to 2.2MHz Frequency Synchronization
• Current Limiting with Hiccup Mode for the Buck and USB
• USB Switch OVP
• ±8kV IEC 61000-4-2 Contact Discharge ESD Rating for the CC1 and CC2 Pins
• ±8kV IEC 61000-4-2 Contact Discharge ESD Rating with External Small ESD Diodes on the DP and DM Pins
• ±15kV IEC 61000-4-2 Air Discharge ESD Rating for the DP, DM, CC1, and CC2 Pins
• Available in a QFN-22 (4mmx4mm) Package
• Available in a Wettable Flank Package

• Available in AEC-Q100 Grade 1
