: MPQ8847A-AEC1TYPE SEB
FAST ACTING GLASS TUBE FUSES SERIES

产品名称：MPQ8847A-AEC1

TYPE SEB FAST ACTING GLASS TUBE FUSES SERIES2022-05-27 17:06:20 更新

特征：6A, 2.7V to 6V, High-Efficiency, Synchronous Step-Down Converter with I2C Interface, AEC-Q100 Qualified

基本介绍 替代型号 购买渠道

▍产品百科

特性

• Flexible via the I2C Interface:• 6V to 1.235V Configurable Output Voltage (VOUT) Range via the I2C, with 5mV Steps
• 85MHz to 2.2MHz Adjustable Switching Frequency (fSW)
• I2C-Compatible Interface up to 3.4Mbps
• Selectable Power-Save Mode via the I2C

• Designed for Heavy Loads:• Up to 6A Load Current
• 40mΩ/22mΩ Internal Power MOSFETs

• Additional Features:• 7V to 6V Input Voltage (VIN) Range
• Internal 165µs Soft-Start Time
• Power Good (PG) Indication
• Current Overload Protection
• Thermal Shutdown
• Available in a QFN-14 (2.5mmx3mm) Package

• Available in AEC-Q100 Grade 1
