• Designed for Automotive Applications:• Wide 2.5V to 5.5V Operating Input Voltage (VIN) Range
• Up to 3A Output Current (IOUT)
• 1% Feedback (FB) Accuracy
• -40°C to +150°C Operating Junction Temperature (TJ) Range
• Available in AEC-Q100 Grade 1

• Increased Battery Life:• 21μA Sleep Mode Quiescent Current (IQ)
• Advanced Asynchronous Modulation (AAM) Mode for Increased Efficiency under Light-Load Conditions

• High Performance for Improved Thermals:• 65mΩ and 35mΩ Integrated Internal Power MOSFETs

• Optimized for EMC and EMI:• 2.4MHz Switching Frequency (fSW)
• MeshConnect™ Flip-Chip Package

• Reduced Board Size and BOM:• Integrated Internal Power MOSFETs
• Integrated Compensation Network
• Available in a Compact QFN-8 (1.5mmx2mm) Package

• Additional Features:• Enable (EN) for Power Sequencing
• Power Good (PG)
• 100% Duty Cycle
• External Soft Start (SS) Control
• Output Discharge
• Over-Voltage Protection (OVP) with Hiccup Mode
• Short-Circuit Protection (SCP) with Hiccup Mode

• Available in a Wettable Flank Package
