: MPQ4312-AEC1TYPE SEB
FAST ACTING GLASS TUBE FUSES SERIES

产品名称：MPQ4312-AEC1

TYPE SEB FAST ACTING GLASS TUBE FUSES SERIES2022-05-27 16:58:40 更新

特征：45V, 2A, Low IQ, Synchronous Step-Down Converter with Frequency Spread Spectrum, AEC-Q100 Qualified

基本介绍 替代型号 购买渠道

▍产品百科

特性

• Wide 3.3V to 45V Operating Input Voltage (VIN) Range
• 2A Continuous Output Current (IOUT)
• 1.7μA Low Shutdown Supply Current (ISHDN)
• 18μA Sleep Mode Quiescent Current (IQ)
• Internal 48mΩ High-Side and 20mΩ Low-Side MOSFETs
• 350kHz to 1000kHz Configurable Switching Frequency (fSW) for Car Battery Applications
• Synchronizable with External Clock
• Out-of-Phase Synchronized Clock Output
• Frequency Spread Spectrum (FSS) for Low EMI
• Symmetric VIN for Low EMI
• Power Good (PG) Output
• External Soft Start (SS)
• 100ns Minimum On Time
• Selectable Advanced Asynchronous Mode (AAM) or Forced Continuous Conduction Mode (FCCM)
• Low-Dropout Mode
• Over-Current Protection (OCP) with Hiccup Mode
• Available in a QFN-20 (4mmx4mm) Package
• Available in a Wettable Flank Package

• Available in AEC-Q100 Grade 1
