: MPQ4488B-AEC1TYPE SEB
FAST ACTING GLASS TUBE FUSES SERIES

产品名称：MPQ4488B-AEC1

TYPE SEB FAST ACTING GLASS TUBE FUSES SERIES2022-05-27 15:19:56 更新

特征：36V, 6A, Step-Down Converter with Configurable Frequency Spread Spectrum and Dual USB Charging Ports, AEC-Q100 Qualified

基本介绍 替代型号 购买渠道

▍产品百科

特性

• Wide 6V to 36V Operating Input Voltage (VIN) Range
• Passes Apple MFI R33 Certification Test
• Passes USB-IF Type-C Certification Test (TID: 3133)
• +135°C Load-Shedding Entry Temperature
• Supports DCP Schemes for BC1.2, Apple 3A Divider Mode, and 1.2V/1.2V Mode
• 5.1V, 5.17V, or 5.3V Selectable Output Voltage (VOUT)
• 100mV Line Drop Compensation
• Accurate USB1/USB2 Output Current Limit
• 18mΩ/15mΩ, Low RDS(ON) Internal Buck Power MOSFETs
• 18mΩ/18mΩ, Low RDS(ON) Internal USB1/USB2 Power MOSFETs
• 250kHz to 2.2MHz Adjustable Switching Frequency (fSW)
• Frequency Spread Spectrum (FSS) for MPQ4488BGU-FD-AEC1 Version
• Forced Continuous Conduction Mode (FCCM)
• Current Limiting with Hiccup Mode for both Buck and USB
• Supports USB Type-C 5V @ 3A DFP Mode
• Available in a QFN-26 (5mmx5mm) Package

• Available in AEC-Q100 Grade 1
