• Easy Scalability:• 16-Channel, 200mA Max Per Channel
• Channels Can Work in Parallel
• Cascade Up to 16 ICs  to Support Up to 256 Channels
• Pin-Configurable Device Address

• Designed for Automotive Applications:• Supports 2.5V Cold Crank
• 40°C to 150°C Operating Junction Temperature (TJ) Range

• Excellent System Efficiency for Improved Thermals:• Adaptive Feedback Control (AFC) for Dynamic, Optimized Pre-Regulator Output
• 300mV Current Sink Headroom Voltage at 200mA
• Headroom Voltage Optimization for Multiple ICs

• Robust Communication for Reliable Control Across Multiple PCBs:• Differential Interface Compatible with 2Mbps Control Area Network (CAN) Transceivers
• 12-Bit Pulse-Width Modulation (PWM) Dimming for Each Channel
• 6-Bit Analog Dimming for Each Channel

• Optimized for EMI/EMC Reduction:• Configurable Phase Shift and Slew Rate
• Frequency Spread Spectrum (FSS) (Internal Clock)
• Selectable PWM Dimming Frequency
• CISPR25 Class 5 Compliant

• Additional Features:• Functional Safety-Capable: Documentation Available to Aid in ASIL System Design
• Failsafe (/FS) Pin and Fault Registers for System Protections and Diagnostics
• LED Short to Ground Protection
• LED Short to Battery Protection
• LED Open Protection
• Thermal Warning and Shutdown
• Open/Short Pin (ISET)
• One-Time Programmable (OTP) Memory
• Available in a QFN-32 (5mmx6mm) Package
• Available in a Wettable Flank Package

• Available in AEC-Q100 Grade 1
