• Designed for Automotive Applications:• 42V Load Dump Tolerance
• Supports 3.1V Cold Crank
• 3A Continuous Output Current (IOUT)
• Wide 3V to 36V Operating Input Voltage (VIN) Range
• -40°C to +125°C Operating Junction Temperature (TJ) Range

• Increases Battery Life:• 1μA Shutdown Current (ISD)
• 20μA Sleep Mode Quiescent Current (IQ)
• Advanced Asynchronous Modulation (AAM) Mode for Increased Efficiency under Light-Load Conditions

• High Performance for Improved Thermals:• Integrated 70mΩ HS-FET and 50mΩ LS-FET
• 65ns Minimum On Time (tON_MIN)
• 50ns Minimum Off Time (tOFF_MIN)

• Optimized for EMC/EMI Reduction:• Frequency Spread Spectrum (FSS) Modulation
• Symmetric VIN Pins (Pin 2 and Pin 10)
• CISPR25 Class 5 Compliant
• 350kHz to 2.5MHz Configurable Switching Frequency (fSW)
• MeshConnect™ Flip-Chip Package

• Additional Features:• Power Good (PG) Output
• Low-Dropout (LDO) Mode
• Over-Current Protection (OCP) with Hiccup Mode
• Available in a QFN-12 (2mmx3mm) Package

• Available in a Wettable Flank Package
