: MP4316TYPE SEB
FAST ACTING GLASS TUBE FUSES SERIES

产品名称：MP4316

TYPE SEB FAST ACTING GLASS TUBE FUSES SERIES2022-05-27 13:54:33 更新

特征：45V, 6A, Low IQ, Synchronous Step-Down Converter with Frequency Spread Spectrum

基本介绍 替代型号 购买渠道

▍产品百科

特性

• Wide 3.3V to 45V Operating Input (VIN) Voltage Range
• Up to 6A of Continuous Output Current (IOUT)
• Low 1.7μA Shutdown Current (ISD)
• 18μA Sleep Mode Quiescent Current (IQ)
• Internal 48mΩ and 20mΩ Power MOSFETs
• 350kHz to 1000kHz Configurable Switching Frequency (fSW) for Car Battery Applications
• External SYNC Clock
• Out-of-Phase Synchronized Clock Output
• Frequency Spread Spectrum (FSS) for Low EMI
• Symmetric VIN for Low EMI
• Power Good (PG) Output
• External Soft Start (SS)
• 100ns Minimum On Time (tON_MIN)
• Selectable Advanced Asynchronous Modulation (AAM) Mode or Forced Continuous Conduction Mode (FCCM)
• Low-Dropout Mode
• Over-Current Protection (OCP) with Hiccup Mode
• Available in a QFN-20 (4mmx4mm) Package

• Available in a Wettable Flank Package
